Appendix 2 Technical Specifications
195
Appendix 2 Technical Specifications
Item Specifications
Rating Input Voltage &
Frequency
Single-Phase: 200~240V 50/60Hz
Three-Phase: 380~440V 50/60Hz
Allowed Input Voltage
Working Range
Single-Phase 220V: 176~264V, frequency＜±5%
Three-phase 380V: 304~456V, voltage imbalance rate ＜ 3%, frequency＜
±5%
Type S2R4GB S2R75GB S21R5GB S22R2GB
Matching Motor Power (kW) 0.4 0.75 1.5 2.2
Rating Output Current (A) 2.4 4.5 7.0 11.0
Type 3R75GB 31R5GB 32R2GB 3004GB 35R5GB
Matching Motor Power (kW) 0.75 1.5 2.2 4.0 5.5
Rating Output Current (A) 2.5 4.0 6.0 9.0 13.0
Type 37R5GB 3011GB 3015GB 3018G 3022G
Matching Motor Power (kW) 7.5 11 15 18.5 22
Rating Output Current (A) 17.0 25.0 32.0 37.0 45.0
Type 3030G 3037G 3045G 3055G 3075G
Matching Motor Power (kW) 30 37 45 55 75
Rating Output Current (A) 60.0 75.0 90.0 110.0 152.0
Type 3093G 3110G 3132G 3160G 3185G
Matching Motor Power (kW) 93 110 132 160 185
Rating Output Current (A) 176.0 210.0 253.0 304.0 342.0
Type 3200G 3220G 3250G 3280G 3315G
Matching Motor Power (kW) 200 220 250 280 315
Rating Output Current (A) 380.0 426.0 480.0 520.0 600.0
Type 3355G 3400G 3500G
Matching Motor Power (kW) 355 400 500
Rating Output Current (A) 680.0 750.0 900.0
Rating Output Voltage 0~rating input voltage
Maximum Overload Current 150% 1minute, 180% 20s
Control Manner V/F control/current vector control
Frequency Control Scope
0.00~650.0Hz(S2R4GB~3004GB)/
0.00~400.00Hz(35R5GB and the above)
Frequency Precision
digital command ±0.01％ (-10℃~+40℃)
analog command ±0.01％ (25℃±10℃)
Set Frequency Resolution digital command 0.01Hz；analog command 1/1000 maximum frequency
Output Frequency Resolution 0.01Hz
Frequency Setting Signal 0~10V, 0~20mA
Acceleration & Deceleration
Time
0.1~3600 s (acceleration and deceleration time are set independently)
