7.1 Peripheral Equipment Connection Diagrams
R
S
T
隔离开关
断路器或熔断器
交流输入电抗器
接触器
输入EMI滤波器
R S T
WVU
ALPHA5000
PE
M
制动电阻
输出EMI滤波器
交流输出电抗器
PB
+
-
电动机
Figure 7-1 S2R4GB~3015GB Peripheral Equipment Connection Diagram
Motor
AC Output Reactor
Output EMI Filter
Braking resistor
Input EMI Filter
AC Input Reactor
Contactor
Breaker or fuse
Isolating switch
