PA: motor parameters
Functi
on
code
Parameter name LCD display Setting range
Factory
setting
Mo
difi
cati
on
MOD
BUS
addres
s
PA.00 Motor selection Motor selection
0: Use motor 1
1: Use motor 2
0 × 0B00
PA.01
Number of poles of
motor 1
Number of
poles
2~56 4 × 0B01
PA.02
Rated power of motor
1
Rated power 0.4~999.9kW
Depend on
model
× 0B02
PA.03 Rated speed of motor 1 Rated speed 0~24000r/min ○ 0B03
PA.04
Rated current of motor
1
Rated current 0.1~999.9A × 0B04
PA.05
No-load current I0 of
motor 1
No-load current 0.1~999.9A × 0B05
PA.06
Stator resistance R1 of
motor 1
Stator
resistance R1
0.001~65.000Ω ○ 0B06
PA.07
Stator leakage
inductance L1 of
motor 1
Stator leakage
inductance L1
0.1~2000.0mH ○ 0B07
PA.08
Rotor resistance R2 of
motor 1
Rotor
resistance R2
0.001~65.000Ω ○ 0B08
PA.09
Mutual inductance
resistance Lm of motor
1
Mutual
inductance
resistance Lm
0.1~2000.0mH ○ 0B09
PA.10
Saturation coefficient
1 of motor 1
Saturation
coefficient 1
0.0%~100.0% ○ 0B0A
PA.11
Saturation coefficient
1 of motor 2
Saturation
coefficient 2
0.0%~100.0% ○ 0B0B
PA.12
Saturation coefficient
3 of motor 1
Saturation
coefficient 3
0.0%~100.0% ○ 0B0C
PA.13
Saturation coefficient
4 of motor 1
Saturation
coefficient 4
0.0%~100.0% ○ 0C0D
PA.14
Saturation coefficient
5 of motor 1
Saturation
coefficient 5
0.0%~100.0% ○ 0B0E
PA.15
Number of poles of
motor 2
Number of
poles
2~56 4 × 0B0F
PA.16
Rated power of motor
2
Rated power 0.4~999.9kW
Depend on
model
× 0B10
PA.17 Rated speed of motor 2 Rated speed 0~24000r/min
○
0B11
PA.18
Rated current of motor
2
Rated current 0.1~999.9A × 0B12
PA.19
No-load current I0 of
motor 2
No-load current 0.1~999.9A × 0B13
PA.20
Stator resistance R1 of
motor 2
Stator
resistance R1
of
0.001~65.000Ω ○ 0B14
PA.21
Stator leakage
inductance L1 of
motor 2
Stator leakage
inductance L1
0.1~2000.0mH ○ 0B15
PA.22
Rotor resistance R2 of
motor 2
Rotor
resistance R2
0.001~65.000Ω ○ 0B16
PA.23
Mutual inductance
resistance Lm of motor
2
Mutual
inductance
resistance Lm
0.1~2000.0mH ○ 0B17
