Alpha 6000S series - Page 84

Chapter 4 Parameter Index
83
Functi
on
code
Parameter name LCD display Setting range
Factor
y
setting
Mo
dif
y
MOD
BUS
addres
s
PC.06
Set speed
(R / min blink)
Set speed
(R / min blink)
0: Not displayed 1: Displayed 0 ○ 0D06
PC.07
Running line
speed
(m/s)
Running line
speed
(m/s)
0: Not displayed 1: Displayed 0 ○ 0D07
PC.08
Set line speed
(m / s blink)
Set line speed
(m / s blink)
0: Not displayed 1: Displayed 0 ○ 0D08
PC.09
Output power
(kW)
Output power
(kW)
0: Not displayed 1: Displayed 0 ○ 0D09
PC.10
Output torque
(%)
Output torque
(%)
0: Not displayed 1: Displayed 0 ○ 0D0A
PC.11
Output voltage
(V)
Output voltage
(V)
0: Not displayed 1: Displayed 1 ○ 0D0B
PC.12 Bus voltage (V) Bus voltage (V) 0: Not displayed 1: Displayed 0 ○ 0D0C
PC.13 AI1 (V) AI1 (V) 0: Not displayed 1: Displayed 0 ○ 0D0D
PC.14 AI2 (V) AI2 (V) 0: Not displayed 1: Displayed 0 ○ 0D0E
PC.15
3004GB and
below
Reserve
Reserve - - *
0D0F
35R5GB and
above:
AI3 (V)
AI3 (V) 0: Not displayed 1: Displayed 0 ○
PC.16
Analog PID
feedback
(%)
Analog PID
feedback
0: Not displayed 1: Displayed 0 ○ 0D10
PC.17
Analog PID
setting
(%, blink)
Analog PID
setting
0: Not displayed 1: Displayed 0 ○ 0D11
PC.18
External count
value
External count
value
0: Not displayed 1: Displayed 0 ○ 0D12
PC.19
Terminal state
(No unit)
Terminal state 0: Not displayed 1: Displayed 0 ○ 0D13
PC.20 Actual length Actual length 0: Not displayed 1: Displayed 0 ○ 0D14
PC.21
Power on
indication
selection
Power on
indication
1~20 1 ○ 0D15
PC.22
Speed display
coefficient
Speed coefficient
0.1~999.9%
Mechanical speed = measured
speed × PC.22 (PG)
Mechanical speed = 120 ×
operating frequency ÷ motor
poles × PC.22 (non-PG)
Set speed = PID set speed ×
PC.22 (PG)
Set speed = 120 × set
frequency ÷ motor poles ×
PC.22 (non-PG)
Notes: Have no effect on actual
speed
100.0
%
○ 0D16
