[2-2] Error Indications on the MAIN Assy debug LED and the product LED
[2-2-1] The debug LED for USB/ETHER UCOM (D601) repeat the operation of two flashing and one second off
A check error of DDR3L SDRAM of USB/ETHER UCOM was generated.
—1—— ! If anything is displayed on the LCD, refer to
each error display contents.
! If nothing, refer to [5-1].
Step Cause Diagnostics Point Item to be Checked Corrective Action Reference
[2-2-2] The debug LED for USB/ETHER UCOM (D601) repeat the operation of five flashing and one second off
A program load error from FLASH ROM (16Mb) of USB/ETHER UCOM was generated.
—1—— ! If anything is displayed on the LCD, refer to
each error display contents.
! If nothing, refer to [5-1].
Step Cause Diagnostics Point Item to be Checked Corrective Action Reference
[2-2-3] The debug LED for USB/ETHER UCOM (D601) keep lighting on
A startup error of USB/ETHER UCOM was generated.
—1—— ! If anything is displayed on the LCD, refer to
each error display contents.
! If nothing, refer to [5-1].
Step Cause Diagnostics Point Item to be Checked Corrective Action Reference
[2-2-4] The debug LED for MAIN CPU/DSP(DSP) (D1501) keep lighting on
An initialization error of MAIN CPU/DSP(DSP) was generated.
—1—— ! If anything is displayed on the LCD, refer to
each error display contents.
! If nothing, refer to [5-1].
Step Cause Diagnostics Point Item to be Checked Corrective Action Reference
[2-2-5] The debug LED for MAIN CPU/DSP(DSP) (D1501) is flashing at a cycle of about 300 ms
An error of the abnormal stop of MAIN CPU/DSP(DSP) was generated.
—1—— ! If anything is displayed on the LCD, refer to
each error display contents.
! If nothing, refer to [5-1].
Step Cause Diagnostics Point Item to be Checked Corrective Action Reference
[2-2-6] The debug LED for MAIN CPU/DSP(ARM) (D1701) repeat the operation of two flashing and one second off
A check error of DDR3L SDRAM of MAIN CPU/DSP was generated.
—1—— ! If anything is displayed on the LCD, refer to
each error display contents.
! If nothing, refer to [5-1].
Step Cause Diagnostics Point Item to be Checked Corrective Action Reference
[2-2-7] The debug LED for SUB DSP (D1901) keep lighting off
A startup error of SUB DSP was generated.
—1—— ! If anything is displayed on the LCD, refer to
each error display contents.
! If nothing, refer to [5-1].
Step Cause Diagnostics Point Item to be Checked Corrective Action Reference
[5] LCD
5.6 STARTUP
ERROR DISPLAY
[5] LCD
5.6 STARTUP
ERROR DISPLAY
[5] LCD
5.6 STARTUP
ERROR DISPLAY
[5] LCD
5.6 STARTUP
ERROR DISPLAY
[5] LCD
5.6 STARTUP
ERROR DISPLAY
[5] LCD
5.6 STARTUP
ERROR DISPLAY
[5] LCD
5.6 STARTUP
ERROR DISPLAY
