Connection of HCE-C300R
1 Direct CAMERA Input Connector
2 Monitor connector extension cable (Included with
HCE-C300R)
Camera Connector
CAMERA 1
HCE-C300R (Sold separately)
REVERSE
(Orange/White)
Camera Control Lead
(Orange/Black)
