Connection of camera and Alpine Navigation system
1 Docking cable (PMD-DOK1E) (sold separately)
2 Audio Input Connector (AUX INPUT)
3 Direct CAMERA Input Connector
4 Camera extension cable (Included with direct
rearview camera)
Camera Connector
RGB Input Terminal
CAMERA 1
Navigation system (Sold separately)
Direct rearview camera (sold
separately)
PMD-B100E
HCE-C117D, etc.
AUX/PRE OUT Connector
AUX/PRE OUT cable
