TECHNICAL SPECIFICATIONS:
MAIN FUNCTIONS:
 DVB S-S2 / T-T2 / C COMBO Signal Analyzer
 All in one 45-2150mhz 75 ohm (“F”) Rf input
 AHD and CVBS video input for CCTV cameras
 3.5” high resolution and high brightness display
 MPEG2-4 SD & HD pictures with Program List, Audio Video PIDs all on one screen.
 Support AAC supplied, DOLBY
 800 MHz processor speed - 8MB Memory
 3000mAh 7.4V replaceable Li-Po Battery with up to 4 hours duration
 Usb Memory Software upgrade and Frequncy Database update
 Pc software for Frequency database update
 30 Catv , 30 Terresterial , 150 Sat programmable plan by PC or Local Keyboard.
 5000 frequency memory
 Numeric Silicone keypad with backlight
 Power save timer functions
 dBm , dBuV and dBmV levels
 Level warnings with speaker
 Led Flash Light
 Test Voltage levels for end user
 Weight only 1 kg with battery
 Size 190mm X 110mm X 60mm
 Temperature range 0 °C to +50 °C
 Humidity Up to 90% non condensing
 With silicone case and padded bag.
 12Volt 1.5A Charger and Car Lighter Charger
SATELLITE:
 DVB S/S2 Measuring SAT: 950 - 2150 Mhz
 -80 to 0 dBm power measurment range
 BER , MER , C/N digital measurments.
 Level Measurement Accuracy 1 dB typ. (2.5 dB max.)
 Spectrum Analyzer: Real Time Spectrum with capture
 50 , 75 , 150 , 300 , 600 , 1200mhz Spectrum Span
 Automatically TP identifies NIT function in spectrum menu
 Tp Control : 4 Tp’s Levels of one and two Satellite in one screen
 Multi Sat Level Control: Dual Feed LNB 2 satellite’s levels in one screen
 Satellite Constellation: Qpsk & 8psk for Sat.
 Auto Port Scan: Diseqc 1.0-1.1-Unicable ports search for sat.
 150 satellite’s more than 2000 TP Frequency current database
 Automatic Signal Quality analysis assistant
 HD & SD Sat Tv Video
 FEC: DVB-S: 1/2, 2/3, 3/4, 5/6, 7/8 - DVB-S2: 1/2, 2/3, 3/4, 5/6, 8/9, 9/10, 2/5, 3/5
 Symbol Rate: 1 to 45MS/s Full automatic selection
 Supports DiSEqC 1.x, DiSEqC 2.x and USALS
 Unicable 1&2 EN50494/EN50607
 Lnb Power Supply : 13V/18V/21V - 500mA
 Supports 32 Lnb Type
 KA , KU, C , L / R band

Alpsat AS06-STC & AHD Specifications

General

Brand	Alpsat
Model	AS06-STC & AHD
Category	Measuring Instruments
Language	English
