FRONT CONTROL PANEL VIEW
RF & LNB INPUT
AHD/CVBS INPUT
AV OUTPUT
12V CHARGE IN
CHARGE LED
POWER LED
USB MEMORY IN
NUMERIC KEYPAD
EDIT – SPAN – FREQ
POINTER
DIRECTION KEYS
MUTE – SAT LIST
ON-OFF BUTTON
LEVEL – C/N - MOTOR
MENU – SAT SELECT
LED LAMP ON/OFF
AV IN SELECT
TV / RADIO SELECT
ESCAPE FUNCTION
OK & ENTER
LED TORCH LAMP
