BAG0217.9 06.22
Work display while driving:
→ The spread rate on both sides and the for-
ward speed are shown.
kg/ha km/h
During operation, the spread rate can be
changed on both sides or on one side by 10%
each time the button is pressed.
Moreover, the originally set spread rate (100%)
can be restored.
(1) Rate on the left
(2) Rate on both sides
(3) Rate on the right
Work display while driving when the spread rate
is changed on one side or both sides:
→ The spread rate in kg/ha is shown separate-
ly for both shutters.
If the deviation from the setpoint is
greater than 5%, the work display
alternately shows the current value
and error message E11.
Wedge-shaped field spreading
The multi-stage, one-sided rate change can also
be used as manual part-width section control
when driving into a wedge and when driving out
of a wedge.
This improves the overlap and therefore the ferti-
liser distribution between the area inside the field
and the headland area.
