2.13 Warning pictograms and other signs on the machine
Always keep all the warning pictograms of the machine clean and in a
legible state. Replace illegible warning pictograms. You can obtain the
warning pictograms from your dealer using the order number (e.g. MD
075).
Warning pictograms - structure
Warning pictograms indicate dangers on the machine and warn
against residual dangers. At these points, there are permanent or
unexpected dangers.
A warning pictogram consists of two fields:
Field 1
is a pictogram describing the danger, surrounded by triangular safety
symbol.
Field 2
is a pictogram showing how to avoid the danger.
Warning pictograms - explanation
The column Order number and explanation provides an explanation
of the neighbouring warning pictogram. The description of the warning
pictograms is always the same and specifies, in the following order:
1. A description of the danger.
For example: danger to fingers or hands from moving operating
elements due to cutting or cutting off.
2. The consequence of non-compliance with the danger protection
instructions.
For example: in these cases there is a danger of extremely seri-
ous injuries leading to the loss of body parts such as fingers or
hands.
3. Instructions for avoiding the danger.
For example: never reach into the danger area when the tractor
engine is running with the cardan shaft/hydraulic system con-
nected.
Only touch moving operating elements once they have come to
a complete standstill.
