BAG0217.9 06.22
The limiter position can be adjusted.
Lift the limiter higher.
→ Smaller effect of the boundary spreading
deflector.
→ Greater throw distance.
Displayed value becomes smaller.
Lower the limiter further down.
→ Greater effect of the boundary spreading
deflector.
→ Smaller throw distance.
Displayed value becomes larger.
After boundary spreading:
1. Deactivate the limiter.
→ The LED is turned off.
2.
If necessary, set the rate on the
boundary side back to 100%.
Hydraulically operated limiter with position sensor
Depending on the boundary spreading
method, the spread rate must be reduced on the
boundary side.
Read the value for the reduction of the
shutter position from the setting chart.
1.
Before boundary spreading / ditch
spreading, reduce the rate on the boundary
side.
2. Actuate the tractor control unit.
→ Activate the limiter for boundary spreading.
The LED shows the activated limiter.
