Product description
ZA
-V BAG0087.11 01.20
31
4 Product description
4.1 Overview of subassemblies
Fig. 3
(1) Frame
(2) Hopper
(3) Spray protection
(4) Spreading discs with spreading vanes
(5) Setting lever for manual spread rate adjustment
(6) Limiter
(7) Folding ladder (Option with extension S)
