Jumpers
Jumper Name Description Page
JP1 Keyboard/USB Power On Enabled/Disabled 3-pin Block P.8
JBAT CMOS RAM Clear 3-pin Block P.8
Connectors
Connector Name Description Page
ATXPWR1 ATX Power Connector 24-pin Block P.14
ATX12V1 ATX 12V Power Connector 8-pin Block P.14
KB PS/2 Mouse & PS/2 Keyboard Connector 6-pin Female P.15
USB from CN1, UL1 USB2.0 Port Connector 4-pin Connector P.15
RJ45LAN from UL1 Gigabit LAN Port Connector RJ-45 Connector P.15
J2 CrossFire Power Connector 4-Pin Block P.15
AUDIO：CN2
6-CH HD Audio Connector 3- phone jack Conn. P.15
FDD1 Floppy Driver Connector 34-pin Block P.16
IDE1 Primary/Secondary IDE Connector 40-pin Block P.16
SATA1～SATA6
Serial ATAII IDE Connectors 7-pin Connector P.16
VGA VGA Connector 15-pin Connector P.17
DVI DVI Connector 29-pin Connector P.17
HDMI HDMIConnector 19-pin Connector P.17
SPDIF_OUT1 Coaxial SPDIF_OUT Connecotr 1-phone Connector P.17
Headers
Header Name Description Page
AUDIO1 SPEAKER, MIC header 9-pin Block P.17
USB1, USB2 USB Port Headers 9-pin Block P.18
SPEAK1 PC Speaker connector 4-pin Block P.18
PWR LED1 Power LED 3-pin Block P.18
JW
_
FP1
(Reset/HDLED/Power
Button/PWR LED)
Front Panel Header
(including IDE activity LED/Reset switch /
Power On Button lead)
9-pin Block P.18
SYSFAN1/2 FAN Headers 3-pin Block P.19
CPUFAN FAN Header 4-pin Block P.19
CDIN1 CD Audio-In Header 4-pin Block P.19
IR IR infrared module Headers 5-pin Block P.19
COM1 Serial Port Connector 9-pin Block P.20
HDMI_SPDIF SPDIF Out header 2-pin Block P.20
WI-FI1 Wi-Fi header 11-pin Block P.20
Expansion Sockets
Socket/Slot Name Description Page
ZIF Socket AM2 CPU Socket 940-pin mPGAB Athlon64 CPU Socket P.10
DDRII1~2 DDRII Module Socket 240-pin DDRII Module Socket P.10
DDRIII1~2 DDRIII Module Socket 240-pin DDRII Module Socket P.13
PCI1∼ PCI2
PCI Slots 32-bit PCI Local Bus Expansion slots P.13
PE2 PCI-Express2.0 x1Slot PCI-Express2.0 x1 Expansion Slots P.13
PE1，PE3
PCI-Express2.0 x16 Slot PCI-Express2.0 x16 Expansion Slots P.13
