AMD 770 User Manual

3
1-2 Specification
Spec Description
Design
∗ ATX form factor 4 layers PCB size: 29.5cm x21.5cm
Chipset
* AMD 770/780V/780G North Bridge Chipset
* AMD SB 700 South Bridge Chipset
CPU Socket AM2
∗ Support 64bit AMD Socket AM2/AM2+AM3 processor utilizing
Flip-Chip Pin Grid Array package
∗ Support for AMD Athlon64 940-pin Dual –Core Athlon 64x2 processor,
Athlon 64 & Sempron Processors with HTT Frequency 1GHz and the
latest AMD Phenom™ FX, quad core AMD Phenom™ processors with
HTT 3.0.
∗ Ready for AM3 CPU
Memory Socket
∗ 240-pin DDRII Module socket x 2
∗ 240-pin DDRIII Module socket x 2
∗ Support 2pcs DDRII533/DDRII667/DDRII800/DDRII1066 Modules
Expandable to 4GB or 2pcs DDRIII 1066/DDRIII 1333 Modules
Expandable to 4GB
∗ Dual channel supported
Expansion Slot
∗ PCI-Express2.0 x16 by 16 Lane 1pcs
∗ PCI-Express2.0 x16 by 4 Lane 1pcs
∗ PCI-Express2.0 x1 slot 1pcs
∗ 32-bit PCI slot x 2pcs
Integrate IDE and
Serial ATA2 RAID
∗ One IDE controllers support PCI Bus Mastering, ATA PIO/DMA and
the ULTRA DMA 33/66/100/133 functions that deliver the data transfer
rate up to 133 MB/s for 2 IDE Devices and for 6 Serial ATA2 ports
providing 300 MB/sec data transfer rate with RAID 0, 1, 10 and JBOD
functions
Gigabit LAN
∗ Integrated RealTek RTL8111CVC PCI-E Gigabit LAN.
∗ Support Fast Ethernet LAN function of providing 10Mb/100Mb/1000
Mb/s data transfer rate
6 CH-Audio
∗ Realtek ALC662 HD 6-channel Audio Codec integrated
∗ Audio driver and utility included
BIOS
∗ AMI 8MB Flash ROM BIOS
Multi I/O
∗ PS/2 keyboard and PS/2 mouse connectors
∗ HDMI Connector x1 (Optional)
∗ VGA Connector x1 (Optional)
∗ DVI Connector x1 (Optional)
∗ USB2.0 port x 4 and headers x 2
∗ RJ-45 LAN Connector x1
∗ Audio connector x1 (Line-in, Line-out, MIC/6CH Audio)
∗ Floppy disk drive connector x1/ Hard disk drive connector x1
∗ Serial Port Header x1
∗ HDMI_SPDIF header x1/ IR Connector x1
∗ WI-FI Header x1
