AMD 770 User Manual

33
XBLUE- 78GA3/XBLUE-78VA3
CMOS Setup Utility-Copyright(C)1985-2005 American Megatrends. Inc.
Onboard SATA Device
Help Item
Onchip SATA Channel Enabled
Onchip SATA Type Native IDE
Option ROM Combined Mode Enabled
SATA IDECombined Mode Enabled
PATA Channel Config SATA as Primary
Onboard PCI IDE Controller Both
Hard Disk Write Protest Disabled
IDE Detect Time Out(Sec) 35
ATA (PI) 80 Pin Cable Detect Host & Device
Select the time out value for
detecting ATA/ATAPI device(s)
↑↓→←
Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
OnChip SATA Channel
Press Enter to enable or disable CnChip SATA Channel.
0n Chip SATA Type
Press Enter to select the SATA type. The optional settings are: Native IDE; RAID; AHCI;
Legacy IDE; IDE
→
AHCI, Hyper Flash (optional)and IDE
→
Hyper Flash(optional).
Option ROM POST Delay
Optional settings are
：
Disabled; 0~7 Second(s)
。
Onboard PCI IDE Controller
The optional settings are Disabled; Primary ; Secondary and Both.
3-7-2 OnBoard Device Control
XBLUE- 77A3
CMOS Setup Utility-Copyright(C)1985-2005 American Megatrends. Inc.
Onborad Device Control
Help Item
Onboard
PCIE Lan Device Enabled
Onboard PCIE Lan BootROM Disabled
HD Audio Azalia Device
Enable
Azalia Front Panel Auto
USB configuration Press Enter
Options
Disabled
Enabled
↑↓→←
Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Discard Changes F6:Standard Settings F7: Optimized Settings
XBLUE- 78GA3/XBLUE- 78VA3
CMOS Setup Utility-Copyright(C)1985-2005 American Megatrends. Inc.
Onboard Device Control
Help Item
Onboard
PCIE Lan Enabled
Onboard Lan BootRom Disabled
HD Audio Azalia Device
Enable
Azalia Front Panel Auto
USB configuration Press Enter
Options
Disabled
Enabled
↑↓→←
Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
