Onboard PCI E Lan Device
Use this item to enable or disable Onboard PCI E Lan
HD Audio Azalia Device
This item allows you to decide to enable/disable the chipset family to support HD Audio.The
optional settings ar: Auto; Enabled and Disabled.
USB Configuration
Press Enter to set values for sub-items as: Legacy USB Support, USB 2.0 Controller Mode
BIOS EHCI Hand-OFF.
3-7-3 Super IO Configuration
XBLUE- 77A3
CMOS Setup Utility-Copyright(C)1985-2005 American Megatrends. Inc.
Super IO Configuration
Configure F71863 Super IO Chipset
Help Item
Power On by Keyboard Disabled
Power On by Mouse Disabled
Onboard Floppy Controller Enabled
Serial Port 1 Address 3F8/IRQ4
Serial Port 2 Address 2F8/IRQ3
Serial Port2 Mode Select IrDA (1.6 us)
IR Duplex Mode Half Duplex
IRTX Pin Select Normal
IRRX Pin Select Normal
IRTx to Rx Delay Select No Delay
IRRx to Tx Delay Select No Delay
PWRON After PWR-Fail Always Off
Allows BIOS to Enable or
Disable Floppy Controller
↑↓→←
: Move Enter: Select +/-/: Value F10: Save ESC:Exit F1:General Help
F5: Discard Changes F6:Standard Settings F7: Optimized Settings
XBLUE- 78GA3/XBLUE- 78VA3
CMOS Setup Utility-Copyright(C)1985-2005 American Megatrends. Inc.
Super IO Configuration
Configure F71863 Super IO Chipset
Help Item
Onboard Floppy Controller Enabled
Serial Port 1 Address 3F8/IRQ4
Serial Port 2 Address 2F8/IRQ3
IrDA Mode Select IrDA (1.6 us)
IR Duplex Mode Half Duplex
IRTX Pin Select Normal
IRRX Pin Select Normal
IRTx to Rx Delay Select No Delay
IRRx to Tx Delay Select No Delay
Allows BIOS to Enable or
Disable Floppy Controller
↑↓→←
: Move Enter: Select +/-/: Value F10: Save ESC:Exit F1:General Help
F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
Onboard Floppy Controller
Select Enabled if your system has a floppy disk controller (FDD) installed on the system
board and you wish to use it. If you install add-on FDC or the system has no floppy drive,
select Disabled in this field. The settings are: Enabled and Disabled.
Serial Port1 Address/ Serial Port2 Address
Use this item to select serial port address for serial port one.
IrDA Mode Select
This item allows BIOS to select mode for serial port 2.
