XBLUE- 78GA3/XBLUE-78VA3
CMOS Setup Utility-Copyright(C)1985-2005 American Megatrends. Inc.
PC Health Status
Help Item
PC Health Status
Smart FAN Configuration Press Enter
H/W Health Function Enabled
CPU Temperature: 50
°
C/122
°
F
System Temperature: 60
°
C/140
°
F
CPUFAN Speed: 2923RPM
SYSFAN1 Speed: N/A
SYSFAN Speed: N/A
NB1.2V : 1.160V
VDIMM : 2.688V
VCORE: 1.132V
NBPCIE: 1.128V
↑↓→←
Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
H/W Health Function,
it displays information list below when set as below. The choice is either Enabled or
Disabled.
CPU Temperature/ System Temperature/CPUFAN/SYSFAN1 Speed/SYSFAN2 Speed
/VLDT/NB//NB1.2V/VDIMM/VCORE/NBPCIE
This will show the CPU/ /System voltage chart and FAN Speed, etc.
3-11 Thermal Throttling Options
XBLUE- 77A3
CMOS Setup Utility-Copyright(C)1985-2005 American Megatrends. Inc.
Thermal Throttling Op
tions
Help Item
CPU Thermal-Throttling Enabled
CPU Throttling Temp 70
°
C
CPU Throttling Duty 50%
Options
Disabled
Enabled
↑↓→←
Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Discard Changes F6:Standard Settings F7: Optimized Settings
XBLUE- 78GA3/XBLUE- 78VA3
CMOS Setup Utility-Copyright(C)1985-2005 American Megatrends. Inc.
Thermal Throttling Op
tions
Help Item
CPU Thermal-Throttling Enabled
CPU Throttling Temp 70
°
C
CPU Throttling Duty 50%
Options
Disabled
Enabled
↑↓→←
Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
CPU Thermal Throttling
Use this item to enable or disable CPU thermal Throttling. The optional settings are: Enable;
Disabled. When set as Enabled, the two following items will show.
CPU Thermal Throttling Temp.
Use this item to set CPU thermal Throttling temperature. The selectable arrange is from 40 to
100 °C.
