System Date
The date format is <day><month><date><year>.
Day
Day of the week, from Sun to Sat, determined by BIOS. Read-only.
Month
The month from Jan. through Dec.
Date
The date from 1 to 31 can be keyed by numeric function keys.
Year
The year depends on the year of the BIOS.
System Time
The time format is <hour><minute><second>.
Primary IDE Master / Slave
SATA Channel 1, 2, 3, 4, 5, 6
While entering setup, BIOS auto detest the presence of IDE devices. This displays the status
of auto detection of IDE devices.
Type:
The optional settings are: Not Installed; Auto; CD/DVD and ARMD
LBA/Large Mode:
The optional settings are Auto; Disabled.
Block (Multi-Sector Transfer):
The optional settings are: Disabled and Auto.
PIO Mode: the optional settings are:
Auto, 0, 1, 2, 3 and 4.
DMA MODE:
the optional settings are Auto, SWDMAn, MWDMAn , UDMAn.
S.M.A.R.T.:
This option allows you to enable the HDD S.M.A.R.T Capability
(Self-Monitoring, Analysis and Reporting Technology). The optional settings are Auto;
Disabled; and ENABLED.
32 Bit Data Transfer:
the optional settings are: Disabled and Enabled.
Floppy A
This item is for specific floppy disk drive settings. Select according to the specification of the
floppy disk you use.
System Memory
This item will show information about the memory modules(s) installed.
3-5 Advanced BIOS Feature
XBLUE- 77A3
CMOS Setup Utility-Copyright(C)1985-2005 American Megatrends. Inc.
Advanced BIOS Features
Advanced Settings
Help Item
¾
CPU Configuration Press Enter
¾
Hard Disk Drives Press Enter
¾
Removable Drives Press Enter
Quick Boot Enabled
1
ST
BOOT Device HDD: PM-WDC WD800
2
nd
Boot Device 1
st
FLOPPY DRIVER
Boot up Num-Lock On
ACPI APIC Support Enabled
MPS Revision 1.1
Configure CPU
↑↓→←
: Move Enter: Select +/-/: Value F10: Save ESC:Exit F1:General Help
F5: Discard Changes F6:Standard Settings F7: Optimized Settings
