3-6 Advanced Chipset Features
The Advanced Chipset Features Setup option is used to change the values of the chipset
registers. These registers control most of the system options in the computer.
XBLUE- 77A3
CMOS Setup Utility-Copyright(C)1985-2005 American Megatrends. Inc.
Advanced Chipset Features
Help Item
Memory Configuration Press Enter
PCI Express Configuration Press Enter
↑↓→←
: Move Enter: Select +/-/: Value F10: Save ESC:Exit F1:General Help
F5: Discard Changes F6:Standard Settings F7: Optimized Settings
XBLUE- 78GA3/XBLUE- 78VA3
CMOS Setup Utility-Copyright(C)1985-2005 American Megatrends. Inc.
Advanced Chipset Features
Help Item
Memory Configuration Press Enter
Internal Graphics Configurat Press Enter
PCI Express Configuration Press Enter
HDMI Audio HDMI
NB Power Management Feature Auto
Primary Video Controller PCI-GFX0-GPP-IGFX
Options
Auto
HDMI
DVI
↑↓→←
Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
HDMI Audio
Use this item to select HDMI audio, the optional settings are: Auto, HDMI and DVI.
Primary Video Controller
This item is for user to choose primary video controller.
3-6-1 Memory Configuration
XBLUE- 77A3
CMOS Setup Utility-Copyright(C)1985-2005 American Megatrends. Inc.
Memory Configuration
Help Item
DRAM Timing Mode Auto
Memory CLK: : 266MHz
CAS Latency (Tcl): :4.0
RAS/CAS Delay(Trcd): :4 CLK
Min Active RAS(Tras): :12 CLK
RAS/RAS Delay (Trrd) :2 CLK
Row Cycle(Trc) :16 CLK
Write Recover Time(Twr) :4 CLK
Bank Interleaving Auto
Enabled Clock to Al1 DIMMs Disabled
Mem CLK Tristate C3/ATL VID Disabled
Memory Hole Remapping Enabled
DCI Unganged Mode Always
Power Down Mode Disabled
Options
AUTO
DCT0
↑↓→←
: Move Enter: Select +/-/: Value F10: Save ESC:Exit F1:General Help
F5: Discard Changes F6:Standard Settings F7: Optimized Settings
To Next Page
