AMD 770 User Manual

32
Port #02 Features ~ Port #03 Features
Press Enter and set values in the sub-items as Ge2 High Speed Mode, Link ASPM, Link
width , Slot Power Limit,w and Comliance Mode
（
780G/780V series motherboard
）
etc..
Port #04 Features~ Port #10 Features
Press Enter and set values in the sub-items as Ge2 High Speed Mode, Link ASPM and
Comliance Mode
（
780G/780V series motherboard
）
etc..
NB-SB Port Features
Press Enter and set values in the sub-items as NB-SB Link ASPM,;NP NB-SB VC1 Traffic
Support and Link Width and Comliance Mode (780G/780V series motherboard
）
etc..
3-7 Integrated Peripherals
XBLUE- 77A3
CMOS Setup Utility-Copyright(C)1985-2005 American Megatrends. Inc.
Integrated Peripherals
Help Item
Onboard SATA Device Press Enter
Onboard Device Control Press Enter
Super IO Configuration Press Enter
↑↓→←
Move Enter: Select +/-/PU/PD: Value F10:Save ESC: Exit F1:General Help
F5: Discard Changes F6:Standard Settings F7: Optimized Settings
XBLUE- 78GA3/XBLUE- 78VA3
CMOS Setup Utility-Copyright(C)1985-2005 American Megatrends. Inc.
Integrated Peripherals
Help Item
Onboard SATA Device Press Enter
Onboard Device Control Press Enter
Super IO Configuration Press Enter
↑↓→←
Move Enter: Select +/-/PU/PD: Value F10:Save ESC: Exit F1:General Help
F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
3-7-1 Onboard SATA Device
XBLUE- 77A3
CMOS Setup Utility-Copyright(C)1985-2005 American Megatrends. Inc.
Onboard SATA Device
Help Item
Onchip SATA Channel Enabled
Onchip SATA Type Native IDE
SATA IDE Combined Mode Enabled
Hard Disk Write Protect Disabled
IDE Detect Time Out(Sec) 35
ATA (PI) 80 Pin Cable Detect Host & Device
Select the time out value for
detecting ATA/ATAPI device(s)
↑↓→←
: Move Enter: Select +/-/: Value F10: Save ESC:Exit F1:General Help
F5: Discard Changes F6:Standard Settings F7: Optimized Settings
