Page #15 background imageLoading...
Page #15 background image
Before Installing the Intellex
Installation and Configuration Guide 5
Display
Note
Pixel count reflects the digital display area and is not affected by NTSC/PAL signal differences.
Record Options
Rear Panel Connectors
Note
* = with optional looping board
** = 16-camera only
Color palette 16,777,216 colors (32 bits)
Gray shades 256 (8 bits)
Display controls Mouse-selectable buttons with indicator lights
Format Menu Mode (pixels) Full Screen Mode (pixels)
1×1 768x576 (Ultra Only)
640×480
1024x768 (Ultra Only)
800×600
2×2 384x288 (Ultra Only)
320×240
512x384 (Ultra Only)
400×300
3×3 256x192 (Ultra Only)
213×160
341x256 (Ultra Only)
267×200
4×4
(16 channel only)
192x144 (Ultra Only)
160×120
256x192 (Ultra Only)
200×150
Record mode Linear, Circular
Image sensitivity High, Normal
Image quality Super, Normal, Extended Record
Record rate
Ultra
NTSC: 480, 240, 120, 60, 30, 15, 7.5, 2.5,
and 1 ips (images per second)
PAL: 400, 200, 100, 50, 25, 12.5, 6.25, 2,
and 0.8 ips
DVMS
NTSC: 120, 60, 30, 15, 7.5, 2.5, and 1 ips
PAL: 100, 50, 25, 12.5, 6.25, 2, and 0.8
ips
LT:
NTSC: 60, 30, 15, 7.5, and 2.5 ips
PAL: 50, 25, 12.5, 6.25, and 2 ips
Connector Use Applies to
Intellex:
Camera In BNC. Composite video input from camera. Ultra, DVMS, LT
Camera Out BNC. Composite video output from camera (passive loop
through). Termination is set within Intellex.
Ultra*, DVMS**, LT**
