Intellex IP
66 Intellex® Ultra
Setting Up Parameters for IP Devices
Set up the parameters for each IP device and each channel of video supported by a device.
Note
To configure the IP address of a device, see the manufacturer’s instructions.
From the main screen view, select Setup. The Setup Options dialog appears.
The server type
depends on the
device category.
Specify the
communications port
of IP device, typically
80 for a
camera/server.
Specify the IP address of
an IP device.
Specify the user name
and password for
authentication when
requesting video from an
IP device.
Specify a name for
each video stream.
Assign a video source to
Intellex camera.
Select a resolution for
each video stream.
Specify the IP source
quality setting for each
video stream.
Select a maximum
allowable image rate
for each video
stream.
Configure the protocol
for each IP device.
Specify an address
for each video
stream. Use a
setting only if the
camera control is set
to use Sensormatic
RS-422 protocol.
