Configuring the Intellex
Installation and Configuration Guide 29
7 Click OK to save all the settings made above.
Setting Up Live Filters
For more information, see the User’s Guide.
Setting Up Motion Detection
1 From the Setup Options screen, click Schedule.
2 If you are using Regular Schedule mode, Camera 1-8 and 9-16 tabs appear. From these tabs,
choose Day Filter > Motion Detection. Click Setup.
Note
If you are using Custom Schedule mode, see step 4b on page 34, to navigate to the live filters.
3 In the draw zone: click and draw the target area, or click All to select the entire area.
Note
Shapes must form an enclosed boundary; you can select multiple shapes. Choose Deactivate,
then click and drag to deselect a previously activated segment. Selecting All decreases the
likelihood of triggering an alarm since a greater percentage of the selected area must have motion
to trigger an alarm.
4 Adjust sensitivity with the Sensitivity slider. Click Apply.
day
night
