Installing Hardware
12 Intellex® Ultra
For DVMS only, connect an optional Live/Playback monitor to the BNC connector on the VACD
board to view live, or playback, video without the Intellex interface.
Note
The layout of the rear panel varies slightly with different motherboards.
INT40
_
BP
Ultra
Live/Playback
BNC connector
USB ports
Printer
Keyboard
Mouse
DVMS/Rackmount
COM2
connector
Printer
USB portsKeyboard
