Configuring the Intellex
Installation and Configuration Guide 25
Trigger Dialog
1 From the Alarm Camera dropdown list, select the alarmed camera that you want to trigger a
response.
2 From the Alarm Types list, select one or more alarm types to trigger the response. You must
select at least one alarm type.
Note
If you select a filter alarm, the source camera (alarm camera) and the target camera (PTZ camera)
cannot be the same. This avoids recursive triggering of dome events.
Response Dialog
1 From the PTZ Camera dropdown list, select the camera that you want to respond to the alarm
trigger. This list includes only cameras that you have configured as PTZ.
2 From the PTZ Action list, select which kind of action to take. Select either Preset Position or
Pattern; whichever you select automatically greys out the other option.
3 Select the position or pattern number from the respective dropdown list.
4 Click OK to confirm your selections.
Note
If there are any invalid conditions, an error message appears. Close the error dialog and correct
the errors before re-trying.
Specify the
conditions that
cause an alarm to
trigger a PTZ
camera action.
Specify the
response to
the alarm.
Default
selection
