Ametek BROOKFIELD CT3 User Manual

AMETEK Brookeld Page 56 Manual No. M08-372-F1116
and identical test blade are 80mm in length with a 1.5mm radius rounded edge.
Requires Fixture Base Table TA-BT-KIT.
TA-TRF TORTILLA ROLL FIXTURE
This xture is used to evaluate changes in corn tortilla texture per AACC
technical paper by measuring the force to roll up a tortilla. Requires Fixture
Base Table TA-BT-KIT.
TA-TSF TAPE STICKINESS FIXTURE
Thisxturemeasurestheadhesiveforcetopulltapeoffofasurface.Multiple
tape samples can be tested simultaneously for average values. Requires Fixture
Base Table TA-BT-KIT.
TA-VBJ VOLODKEVITCH BITE JAWS
Compression test used to simulate the shearing action of the front incisors as
they bite through a food item, generating an indication of sample toughness or
brousness.Consistingofbothupperandlowerjaws,thecompressivemovement
ofthetravellingbeamimitatesthehuman“bitingaction”.RequiresFixtureBase
Table TA-BT-KIT.
TA-WSP WIRE SHEAR PLATE
Thisxtureisanaluminiumplatewithaperturetopasswirecuttingbladethrough
asampleforsheartypetesting.Goodforproductswithsignicantstickiness
like cheese or butter. Includes TA53* cutting wire. Requires Fixture Base
Table TA-BT-KIT.
TA-WB-PY WATER JACKET SAMPLE CUP FOR TEMP CONTROL
Water jacketed cup assembly with RTD temperature probe and CABLE for
temperature control on semi solid samples.
QTS-AVJ AdjustableviceJigsleftoverfromQTSinventory.
Miscellaneous
TA-RT-5 T-Bolt (2)
TA-RT-3 Thumbnut (2)
TA-TBLT Table Bolt Nut
TA-BT-5 Base Table Insert for TA-BT-KIT
TA51 M6 to M3 Probe Adapter
TA52-4 Packet of 5 Blades for TA52
TA-LVL Bubble Level
