Ametek JOFRA ITC-320 A

123312 03 17-08-2004 15
Insertion tubes are selected on the basis of the diameter of the sensor
to be calibrated.
Use the table for insertion tubes in section 10.0 to find the correct part
number.
Alternatively, you may order an undrilled insertion tube and drill the
required hole yourself. The finished dimension should be as follows:
• Sensor diameter +0.2
+0.05/-0 mm.
