20 17-08-2004 123312 03
UP ARROW button used to adjust temperature values
(value increases) and to select menu options.
Display
Fig. 5
Pos. Description
CHECKMARK displayed when the calibrator is stable.
SWITCH TEST input open.
SWITCH TEST input closed.
AUTO STEP symbol used to indicate that the function is
active (symbol flashes repeatedly).
Used to display set-temperatures, time-until-stable and
parameter values in the menu system.
Minute time unit for bottom display.
Fahrenheit temperature unit for bottom display.
Celsius temperature unit for bottom display.
Fahrenheit temperature unit for top display.
