52 17-08-2004 123312 03
Pos. Description
Calibrator
Ø4.2 mm insertion tube
Ø4 mm Pt 100 sensor with traceable certificate
DTI 1000 reference precision thermometer with traceable
certificate
TECHNICAL SPECIFICATIONS – ALL MODELS
All specifications are given with an ambient temperature of
23°C/73.4°F ± 3°C/5.4°F
GENERAL SPECIFICATIONS
MECHANICAL SPECIFICATIONS
Dimensions l × w × h 241 × 139 × 375mm / 9.5 × 5.5 × 14.8 inch
Weight
ITC-155 A: 7.6 kg / 16.8 lb
ITC-320 A: 6.5 kg / 14.3 lb
ITC-650 A: 8.5 kg / 18.7 lb
Bore diameter/depth of well ITC-155 A: ø 20 mm / 150 mm
ø 0.79 inch / 5.9 inch
ITC-320/650 A: ø 30 mm / 160 mm
ø 1.18 inch / 6.3 inch
Weight non-drilled insert ITC-155 A: 130 g / 4.6 oz
ITC-320/650A: 940 g / 33.2 oz
POWER SUPPLY
Line voltage/frequency ITC-155/320A:
90-127VAC / 180-254VAC 45-65 Hz
ITC-650 A:
100-127VAC / 200-254VAC 45-65 Hz
Power consumption ITC-155 A: 150 VA
ITC-320/650A: 1150 VA
