98 ARX 23-2 T4i, ARX 26-2 T4i

S591001

S591002

S591013

S591000

2.7 Machine operation and use

Raising procedure

Release the canopy by pulling out the lever (1) slightly and raise

the canopy.

Mount the screws (2x) at the bottom of the plastic canopy.
