160 ARX 23-2 T4i, ARX 26-2 T4i

593065

593066

593067

3.6 Lubrication and maintenance operations

3.6.42 Replacement of hoses of the fuel system

Replace hoses of the fuel system.

3.6.43 Replacement of suction hoses

Replace suction hoses.
