Ammann ARX 23-2 - Machine Lubrication

139ARX 23-2 T4i, ARX 26-2 T4i
615096B
593076
MAINTENANCE MANUAL
3.6.19 Machine lubrication
Remove the caps on the grease nipples.
Before lubricating, clean the grease nipple.
Connect the grease gun to the grease nipple.
Lubricate the bearing suciently until the lubricant starts to
ow out.
Install the protective cover in place.
Note
After every machine cleaning or steam cleaning, lubricate the
bearing again.
Edge cutter
Pins 2×
Steering linear hydraulic motor
Turn the steering mechanism up to the stop to lubricate the hy-
draulic cylinder. Turn the machine slightly to the right and to
the left. This will loosen the bearings.
