2.7 Machine operation and use
2.7.9 Infrathermometer (optional
equipment)
It is activated by turning on the key in the switch box (19) and
it displays the temperature of the bitumen surface being rolled.
The measured temperature in °C is indicated on the display.
Control
In the following text, the “OK button” means the vibration but-
ton (12). The “select button” means the sprinkling button (13).
These buttons only work on the right travel control.
Procedure to set the units of measure °C or °F
After setting the required parameters on the display of the infra
thermometer, the values are saved automatically.
Turn the key in the ignition box to the "I" position.
Remove the cover.
