15ARX 23-2 T4i, ARX 26-2 T4i
SPECIFICATION MANUAL
ARX 23-2 ARX 23-2C ARX 26-2 ARX 26-2C
EU Stage IIIA / U.S. EPA Tier 4i
Engine
Manufacturer - Kubota Kubota Kubota Kubota
Type -
D1803-M-DI-
E3B
D1803-M-DI-
E3B
D1803-M-DI-
E3B
D1803-M-DI-
E3B
Power according to SAE J1995 kW 24.8 24.8 24.8 24.8
Number of cylinders - 3 3 3 3
Cylinder capacity cm
3
(cu in) 1826 (111) 1826 (111) 1826 (111) 1826 (111)
Nominal speed min
-1
(RPM) 2100 / 2400 2100 / 2400 2100 / 2400 2100 / 2400
Maximum torque Nm (ft lb)/rpm 115.6 / 1600 115.6 / 1601 115.6 / 1602 115.6 / 1603
Average fuel consumption l/h (gal US/h) 3.1 (0.8) 3.1 (0.8) 3.1 (0.8) 3.1 (0.8)
Engines complies with emission
regulations
-
EU Stage IIIA, U.S.
EPA Tier 4 Interim
EU Stage IIIA, U.S.
EPA Tier 4 Interim
EU Stage IIIA, U.S.
EPA Tier 4 Interim
EU Stage IIIA, U.S.
EPA Tier 4 Interim
Cooling system of engine - Liquid Liquid Liquid Liquid
Brakes
Operating - Hydrostatic Hydrostatic Hydrostatic Hydrostatic
Parking -
Mechanical
multiple-disc
Mechanical
multiple-disc
Mechanical
multiple-disc
Mechanical
multiple-disc
Emergency -
Mechanical
multiple-disc
Mechanical
multiple-disc
Mechanical
multiple-disc
Mechanical
multiple-disc
Vibration
Frequency I Hz (VPM) 58 (3480) 58 (3480) 58 (3480) 58 (3480)
Frequency II Hz (VPM) 66 (3960) 66 (3960) 66 (3960) 66 (3960)
Amplitude I mm (in) 0.5 (0.02) 0.5 (0.02) 0.5 (0.02) 0.5 (0.02)
Amplitude II mm (in) 0.5 (0.02) 0.5 (0.02) 0.5 (0.02)
0.5 (0.02)
Centrifugal force I kN 33.4 33.4 38.8 38.8
Centrifugal force II kN 39.9 39.9 46.5 46.5
Type of drive - Hydrostatic Hydrostatic Hydrostatic Hydrostatic
Watering
Type of watering - Pressure Pressure Pressure Pressure
Number of pumps - 1 1 1 1
Number of ltrations - 2 2 2 2
Fluid capacities
Fuel l (gal US) 35 (9.2) 35 (9.2) 35 (9.2) 35 (9.2)
Water for drum watering l (gal US) 190 (50.2) 190 (50.2) 190 (50.2) 190 (50.2)
Engine (oil lling) l (gal US) 7 (1.8) 7 (1.8) 7 (1.8) 7 (1.8)
Cooling system l (gal US) 6.7 (1.8) 6.7 (1.8) 6.7 (1.8) 6.7 (1.8)
Hydraulic system l (gal US) 28.5 (7.5) 28.5 (7.5) 28.5 (7.5) 28.5 (7.5)
Wiring
Voltage V 12 12 12 12
Battery capacity Ah 77 77 77 77
