30 ARX 23-2 T4i, ARX 26-2 T4i
1700 kg
5511 lb
2500 kg
β
WLL
3747 lb
α
30° ≤ β ≤ 60°
0° ≤ α ≤ 60°
LC
4055
anti-adhesive
liquid
3518
3868
85 100
0
2406
bz2406
2.1 Main safety precautions
16 Fastening hole When transporting, fasten the machine only in these
holes.
17 Suspension diagram To lift the machine, use slings with asucient lifting ca-
pacity according to chapter Loading the machine. Before
hanging, lock the articulation of the machine.
18 Set of lters
21 California Proposition 65 Exhaust gases and their components, operating uids,
batteries and other machine accessories contain chemi-
cals known in the state of California to be substances
which may cause cancer, congenital defects and other
reproduction problems.
When handling these substances, abide by relevant safe-
ty precautions.
Further information see www.p65warnings.ca.gov
19 Engine speed adjustment
in per cents
22 Emulsion sprinkling tank
20 Engine speed
