69ARX 23-2 T4i, ARX 26-2 T4i
OPERATING MANUAL
Machine travel and reversing with vibration
It is forbidden to enable the vibration when the machine is standing.
If the parking brake indicator lamp (29) is on, move the travel control (11) from the parking brake (P) position to the (0) position.
Manual mode
• Use the vibration mode switch (7) to set the manual mode.
• Use the engine speed control (3) to set the working engine speed I or II.
• Use the vibrating drum selector (9) to select the front drum vibration or front and rear drum vibration.
• Use the travel mode switch (4) to set mode “1” – the working mode of the machine.
• Using the travel control (10) select the forward (F) or reverse (R) travel direction.
Turning on
• Turn on the vibration with the switch (12).
Turning o
• Turn o the vibration with the switch (12).
Note
When the travel control (11) is in the zero position (0), vibration of the machine is still active. Vibration is automatically turned o in the
parking brake position (P).
Automatic mode
• Use the vibration mode switch (7) to set the automatic mode.
• Use the engine speed control (3) to set the working engine speed I or II.
• Use the vibrating drum selector (9) to select the front drum vibration or front and rear drum vibration.
• Use the travel mode switch (4) to set mode “1” – the working mode of the machine.
• Using the travel control (11) select the forward (F) or reverse (R) travel direction.
Turning on
• Press the vibration switch (12).
• The vibration will be automatically turned on when the travel speed is more than 1–2km/h (0.6–1.2mph).
• The vibration will be automatically turned o when the travel speed is less than 1–2km/h (0.6–1.2mph).
• Vibration and sprinkling remains enabled even after the travel control (11) has been smoothly shifted through the zero position (0).
Turning o
• Press the vibration switch (12).
Note
When the travel control (11) is kept in the zero position (0) or set to the parking brake position (P), vibration and sprinkling is automati-
cally turned o.
Panic response
The immediate stop of the machine using the travel control (11) applies to all of the travel modes of the machine. When the travel
control (11) is changed to the opposite position through (0) within 1 second, the machine will stop – the parking brake will be engaged
and the engine will keep running, i.e. panic response. When the machine vibration is on, the vibration will stop also when the manual
vibration mode is selected. The machine can start moving again after the travel control (11) is changed to the parking brake position
(P) and the travel direction (F/R) is selected.
