Getting Started
9
Fig. 2
5. Assembling the Eyepiece
1) Remove the cover of eyepiece tube ① .
2) Insert the eyepiece ② into the eyepiece tube until
touching the bottom. (See Fig. 2)
Fig. 3
6. Assembling Objective
1) Rotate the coarse focusing knob to lower the stage.
2) Install the objective into the microscope nosepiece from
the lowest magnification to the highest in a clockwise
direction from the rear. (See fig.3)
Fig. 4
7. Plug in the microscope and turn it on. User dimmer to
adjust light.
Dimmer
