AmScope ME580 Series - Definition of Parts (Continued)

10
ME580 Series
User’s Manual
Parts
Denion of Parts (Connued)
Abbe Condenser (w/ Iris)
Focuses and controls the amount of light that hits the slide from the base illuminator
Ocular Tube / Eyepieces
The tube which extends from the microscope head and accepts the eyepieces, which enlarge the image
from the objecve to a plan near the user’s eye for ease of viewing.
Abbe Condenser
Eyepieces
