TPI Configuration and Usage
12
AXB-TPI/3 Touch Panel Interface 3
8. While in AxcessX, press the F4 key to access the Communications menu.
9. Open the Configuration page by selecting Configure, from the Communication menu. Use this
menu to configure the communication parameters between the computer and the TPI/3. If your
computer is connected properly, communicating correctly, and on the proper COM setting,
PUSH[1,1] appears at the bottom of the main program screen after restarting the program.
The Configure page displays a window of communication options. Defaults are COM 1,
9600-baud (bits per second) data rate, and LPT1.
10. Choose a COM port and set its parameters (bits per second and LPT number). The preferred
COM port parameters are listed in the following table.
11. Press F10 to save the changes and exit the Configure page.
12. Select Terminal Emulator from the Communications menu to enter the Communications
Terminal window. Since the ESC key is a legal character in the communications mode, use the
F10 key to exit from this menu option.
Terminal Emulator (Ctrl-t) displays a communications window. Highlighting this option and
pressing ENTER places a "TERMINAL" window on the monitor. The menu bar along the top
of the window provides controls for changing the display and communications options.
13. Type
HELLO and press ENTER. This message is used to verify that serial communication has
been established. When a valid connection exists, the device responds with
HOW ARE YOU
DOING.
14. Type ECHO ON (will not appear) and press ENTER. Although there are no characters
displayed, the window is now active and ready to receive commands.
15. Follow the remaining setup procedures for an Axcess system configuration as listed in
the Setting Up serial procedures section on page 11. The commands used for AxcessX and
HyperTerminal are the same.
COM Port Parameter Settings
Parameter Setting
Bits per second 38,400
Data bits 8 bits
Parity No parity
Stop bits 1
Flow control None
<ASC> - Display (ASCII, Hexadecimal, Decimal) F2-Changes the character bits.
8 - Character Bits (5, 6, 7, 8) F3-Changes the parity.
N - Parity (E, O, M, S, N) F4-Changes the number of stop bits.
1 - Stop Bits (1 or 2) F9-Opens the Configure menu.
F1- Changes the display format. F10-Returns to the main screen.
The HELLO characters will not appear on-screen until ECHO ON is entered into the
Terminal Emulator.
