AMX AXB-TPI/3 User Manual

TPI Configuration and Usage
15
AXB-TPI/3 Touch Panel Interface 3
Refer to the Specifications table on page 3 for the horizontal, vertical, and refresh rates available for
the output coming from the TPI/3.
3. Continue the setup process by assigning touch devices to the monitor. Refer to the following
section for more information.
Assigning a touch device
Use the following command and device IDs to set the mouse driver:
Resolution <hor>x<vert>:<refresh>
Allows you to set the resolution (horizontal/vertical) and refresh rate of the touch panel.
PRGM EX. 1
Resolution 1024x768:60
This sets the TPI/3 to send a video signal at 1024 x 768 with a refresh rate of 60 Hz.
PRGM EX. 2
If the video is blurry, try a different refresh rate and/or resolution. Check the output
device to verify you are using refresh rates and resolution settings are compatible
with the device.
Mouse<# for touch driver>
This command allows you to see the characters on the display as you type them. The following table lists
the supported touch devices and their associated ID’s.
Refer to the Appendix section on page 79 for a listing of touch panel drivers that have been tested with the
TPI/3.
PRGM EX. 3
Supported Touch Devices
Touch Device ID
No touch device 00
Microsoft serial mouse 01
2nd Microsoft Serial Mouse
(MX-MM Mobile Mouse
®
)
02
Dynapro
®
touch monitor 10
MicroTouch
®
touch monitor 11
Elo IntelliTouch
®
and VTM-D15/A
touch monitors
12
Elo AccuTouch
®
touch monitor 13
EZ Screen
®
touch monitor 15
External touch driver FF
Mouse 12
This sets the TPI/3 touch device to the VTM-D15/A MultiMedia Touch Panel or Elo IntelliTouch panel.
PRGM EX. 4
If the assigned ELO driver does allow calibration of the monitor, try the alternate ELO
touch driver and repeat step 2.
