AMX MST-1001 User Manual

MST/D-1001 - 10.1" S Series Touch Panels
8
Modero S Series G4 Touch Panels Instruction Manual
MST-1001 Specifications (Cont.)
TOUCH SCREEN DISPLAY • Display Type: TFT Active Matrix Color LCD
• Display Size (WH): Landscape: 9.1" x 5.9" (230 mm x 149 mm), 10.8" (274 mm)
diagonal
• Viewable Area (WH): Landscape: 8.5" x 5.4" (217 mm x 136 mm ), 10.0" (256 mm)
diagonal
• Resolution: Landscape: 1280x800
• Aspect Ratio: Landscape: 16:9
• Brightness: 350 cd/m2
• Contrast Ratio: 800:1
• Color Depth: 16.7M colors
• Illumination: LED
• Touch Overlay: Resistive
VIEWING ANGLE 85°/85°/85°/85° (Up/Down/Left/Right)
MEMORY • SDRAM: 512 MB
•Flash: 4 GB
• Maximum Project Size: 2.4 GB flash available to user
COMMUNICATIONS • Ethernet: 10/100 port, RJ-45 connector. Supported IP and IP-based protocols: UCP,
TCP, ICMP, ICSP, IGMP, DHCP, Telnet, FTP, DNS, RFB (for VNC), HTTP
• USB: (1) USB host 2.0, Type A port: Firmware upgrade, touch panel file transfer, JPEG
image viewer, HID Peripherals
• Bluetooth®: Mouse/Keyboard: HID Profile v1.1, requires MXA-BT, Bluetooth USB
Adapter for Modero X/S Series Touch Panels (FG5968-19) and MXA-HST, Bluetooth
Handset for Modero X/S Touch Panels (FG5968-17)
VIDEO • Supported Video Codecs:
MPEG2-TS: MPEG-2 Main Profile@High Level up to 720p at 25 fps (decode)
MPEG-2-TS: H.264 High Profile@Layer 4, AAC-LC up to 720p at 25 fps (decode)
MJPEG up to 720p at 25 fps (decode)
• Supported Video Transport Streams: MPEG-TS for MPEG2 and H.264; HTTP for
MJPEG
• Max Number of Active Video Streams: One decode
AUDIO • Microphone: -42 dB ±3 dB sensitivity FET microphone
• Speakers: 4 ohm, 1.5 Watt, 500 Hz cutoff frequency
• Supported Audio Codecs:
MP2 Layer I and II, MP3 (8 kHz, 11.025 kHz, 12 kHz, 16 kHz, 22.05 kHz, 24 kHz, 32
kHz, 44.1 kHz, 48 kHz)
AAC-LC (8 kHz, 96 kHz)
G.711 with µLaw (VoIP encode/decode at 8 kHz)
• File Formats: WAV, MP3 (as part of touch panel file only - no USB storage)
• Intercom: Full Duplex VoIP, SIP v2.0 (supported with AMX-CSG)
GRAPHICS ENGINE AMX G4: AMX's exclusive, powerful G4 graphics engine – the driving force behind the
advanced graphics and image processing capability on a variety of AMX Touch Panels
and other devices (see TPD4 Operations Guide for more information)
EMBEDDED APPLICATIONS • Remote Management: VNC Server, G4 Web Control
• Panel-to-Panel Conferencing: Receives audio and video and returns audio for panel-
to-panel communication
• Audio Conferencing: Audio (Full Duplex Intercom)
FRONT PANEL
COMPONENTS
Sleep Button: Sleep button to activate sleep mode and powering off. Also provides
access to setup pages (can be disabled)
CONNECTIONS • Ethernet: 10/100 port, RJ-45 connector
• USB: (1) USB host 2.0, Type A port
• Power: PoE (Power over Ethernet), 802.3af, class 3

AMX MST-1001 Specifications

General

Aspect ratio	16:9
Screen shape	Flat
Display diagonal	10 \
Touchscreen type	Tabletop
Display brightness	350 cd/m²
Display resolution	1280 x 800 pixels
Display technology	LED
Touchscreen technology	Resistive
Viewable size diagonal	256 mm
Contrast ratio (typical)	800:1
Display number of colors	16.78 million colors
Product color	Black
Ethernet LAN (RJ-45) ports	1
Display viewable area (HxV)	136 x 217 mm
Power supply type	DC
Power consumption (standby)	4.5 W
Power consumption (typical)	7.5 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 85 %
Operating relative humidity (H-H)	20 - 85 %
Wall mountable	No
HDMI ports quantity	0
Graphics card	AMX G4
Internal memory	512 MB
Internal memory type	DDR
RMS rated power	1.5 W

Weight and Dimensions

Depth (without stand)	103 mm
Width (without stand)	264 mm
Height (without stand)	157 mm
Weight (without stand)	5530 g
