MST/D-1001 - 10.1" S Series Touch Panels
11
Modero S Series G4 Touch Panels Instruction Manual
Touch Panel Aspect Ratio
While the touch panel screen physical dimensions fall between 16:9 and 16:10, any incoming video stream can be scaled
to 16:9 if needed. This may lead to some letter boxing around the video in some cases.
MSD-1001-L Specifications (Cont.)
GRAPHICS ENGINE AMX G4: AMX's exclusive, powerful G4 graphics engine – the driving force behind the
advanced graphics and image processing capability on a variety of AMX Touch Panels
and other devices (see TPD4 Operations Guide for more information)
EMBEDDED APPLICATIONS • Remote Management: VNC Server, G4 Web Control
• Video Conferencing: Panel-to-panel and video chat (the MSD-1001 receives video and
returns audio)
• Audio Conferencing: Audio (Full Duplex Intercom)
FRONT PANEL
COMPONENTS
Sleep Button: Sleep button to activate sleep mode and power off. Also provides access to
setup pages (can be disabled)
Programmable Red/Green LEDs: Programmable red/green LED in the front, left and right
sides of the panel, LEDs are beautifully recessed and nearly invisible when not lit
CONNECTIONS • Ethernet: 10/100 port, RJ-45 connector
• USB: (1) USB host 2.0, type A port
• Power: PoE (Power over Ethernet), 802.3af, class 0
ENVIRONMENTAL • Temperature (Operating): 32° F to 104° F (0° C to 40° C)
• Temperature (Storage): 4° F to 140° F (-20° C to 60° C)
• Humidity (Operating): 20% to 85% RH
• Humidity (Storage): 5% to 85% RH
• Power ("Heat") Dissipation:
On: 27.3 BTU/hr
Standby: 10.9 BTU/hr
INCLUDED ACCESSORIES • Installation Template 10.1" S Series (68-2265-03)
OPTIONAL ACCESSORIES • MSA-MMK-10, Multi Mount Kit, 10.1" Modero S Wall Mount (FG2265-11)
• MSA-RMK-10, Rack Mount Kit for 10" Modero S Series Wall Mount Touch Panel
(FG2265-14)
• MSA-AMK-10, Any Mount Kit for 10.1" Modero S Series Wall Mount Touch Panel
(FG2265-26)
• MXA-MP, Modero X/S Series Multi Preview (FG5968-20)
• MXA-MPL, Modero X/S Series Multi Preview Live (FG5968-10)
• PS-POE-AF-TC, PoE Injector, 802.3AF Compliant (FG423-83)
• NXA-ENET8-2POE, Gigabit Ethernet Switch (FG2178-63)
• MXA-BT, Bluetooth USB Adapter for Modero X/S Series Touch Panels (FG5968-19)
• MXA-HST, Bluetooth Handset for Modero X/S Series Touch Panels (FG5968-17)
• MXA-CLK, Modero X/S Series Screen Cleaning Kit (FG5968-16)
• CB-MSA-10, Rough-In Box and Cover Plate for 10.1" Modero S Series Wall Mount
Touch Panel (FG2265-08)
