MST/D-431 - 4.3" S Series Touch Panels

Modero S Series G4 Touch Panels Instruction Manual

Touch Panel Aspect Ratio

While the touch panel screen physical dimensions fall between 16:9 and 16:10, any incoming video stream can be scaled

to 16:9 if needed. This may lead to some letter boxing around the video in some cases.

MSD-431-L Specifications (Cont.)

FRONT PANEL

COMPONENTS

• Sleep Button: Sleep button to activate sleep mode and power off. Also provides access

to setup pages (can be disabled)

• Programmable Red/Green LEDs: Programmable red/green LED in the front, left and

right sides of the panel, LEDs are beautifully recessed and nearly invisible when not lit

CONNECTIONS • Ethernet: 10/100 Auto MDI-X port, RJ-45 connector

• USB: (1) USB host 2.0, type A port

• Power: PoE (Power over Ethernet), 802.3af, class 3

ENVIRONMENTAL • Temperature (Operating): 32° F to 104° F (0° C to 40° C)

• Temperature (Storage): 4° F to 140° F (-20° C to 60° C)

• Humidity (Operating): 20% to 85% RH

• Humidity (Storage): 5% to 85% RH

• Power ("Heat") Dissipation:

On: 13.6 BTU/hr

Standby: 10.9 BTU/hr

INCLUDED ACCESSORIES • Installation Template 4.3" S Series (68-5968-02)

OPTIONAL ACCESSORIES • MSA-MMK-43, Multi Mount Kit, 4.3" Modero S Wall Mount (FG2265-13)

• MXA-MP, Modero X/S Series Multi Preview (FG5968-20)

• MXA-MPL, Modero X/S Series Multi Preview Live (FG5968-10)

• PS-POE-AF-TC, PoE Injector, 802.3AF Compliant (FG423-83)

• NXA-ENET8-2POE, Gigabit PoE Ethernet Switch (FG2178-63)

• MXA-BT, Bluetooth USB Adapter for Modero X/S Series Touch Panels (FG5968-19)

• MXA-HST, Bluetooth Handset for Modero X/S Series Touch Panels (FG5968-17)

• CB-MSA-43, Rough-In Box and Cover Plate for the 4.3" Wall Mount Modero S Series

Touch Panel (FG2265-10)

• MXA-CLK, Modero X/S Series Screen Cleaning Kit (FG5968-16)

• MXA-USB-C, USB Port Covers for the Modero X/S Series Touch Panels (FG5968-18)
