AMX MST-1001 User Manual

Installing Wall-Mount (MXD) Panels
38
Modero S Series G4 Touch Panels Instruction Manual
Removing The Touch Panel From the Backbox After Wall Installation
Occasionally it may be necessary to remove the touch panel from the wall to perform routine maintenance, firmware
upgrade or troubleshooting. This section describes the best methods for removing to touch panel from the Backbox
without damaging either.
1. With fingertips placed on the top edge of the bezel, press down on the panel firmly but gently to unhinge the top
clips of the Backbox. Do not press on the glass!
2. Once the top clips are release from the touch panel, pull the top panel away from the wall and lift the touch panel up
to separate it from the Backbox. Do not pull on the cables.
3. Unplug the cables if the touch panel needs to be removed for maintenance.
4. To reattach the panel to its Backbox, latch the panel onto the top hooks on the Backbox and push it down onto the
bottom snaps. Press gently but firmly on the ends until the snaps “click” to lock it down.
Always push down on the frame of the touch panel. NEVER push on the glass.

AMX MST-1001 Specifications

General

Aspect ratio	16:9
Screen shape	Flat
Display diagonal	10 \
Touchscreen type	Tabletop
Display brightness	350 cd/m²
Display resolution	1280 x 800 pixels
Display technology	LED
Touchscreen technology	Resistive
Viewable size diagonal	256 mm
Contrast ratio (typical)	800:1
Display number of colors	16.78 million colors
Product color	Black
Ethernet LAN (RJ-45) ports	1
Display viewable area (HxV)	136 x 217 mm
Power supply type	DC
Power consumption (standby)	4.5 W
Power consumption (typical)	7.5 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 85 %
Operating relative humidity (H-H)	20 - 85 %
Wall mountable	No
HDMI ports quantity	0
Graphics card	AMX G4
Internal memory	512 MB
Internal memory type	DDR
RMS rated power	1.5 W

Weight and Dimensions

Depth (without stand)	103 mm
Width (without stand)	264 mm
Height (without stand)	157 mm
Weight (without stand)	5530 g
