Modero S Series G4 Touch Panels Instruction ManualMST/D-701 - 7" S Series Touch Panels
17
Modero S Series G4 Touch Panels Instruction Manual
Touch Panel Aspect Ratio
While the touch panel screen physical dimensions fall between 16:9 and 16:10, any incoming video stream can be scaled
to 16:9 if needed. This may lead to some letter boxing around the video in some cases.
MSD-701-L Specifications (Cont.)
AUDIO • Microphone: -42 dB ±3 dB sensitivity FET microphone
• Speakers: 4 ohm, 1.5 Watt, 500 Hz cutoff frequency
• Supported Audio Codecs:
MP2 Layer I and II, MP3 (8 kHz, 11.025 kHz, 12 kHz, 16 kHz, 22.05 kHz, 24 kHz, 32
kHz, 44.1 kHz, 48 kHz)
AAC-LC (8 kHz, 96 kHz)
G.711 with µLaw (VoIP encode/decode at 8 kHz)
• File Formats: WAV, MP3 (as part of touch panel file only - no USB storage)
• Intercom: Full Duplex VoIP, SIP v2.0 (supported with AMX-CSG)
GRAPHICS ENGINE AMX G4: AMX's exclusive, powerful G4 graphics engine – the driving force behind the
advanced graphics and image processing capability on a variety of AMX Touch Panels
and other devices (see TPD4 Operations Guide for more information)
EMBEDDED APPLICATIONS • Remote Management: VNC Server, G4 Web Control
• Panel-to-Panel Conferencing: Receives audio and video and returns audio for panel-
to-panel communication
• Audio Conferencing: Audio (Full Duplex Intercom)
FRONT PANEL
COMPONENTS
• Sleep Button: Sleep button to activate sleep mode and powering off. Also provides
access to setup pages (can be disabled)
• Programmable Red/Green LEDs: Programmable red/green LED in the front, left and
right sides of the panel, LEDs are beautifully recessed and nearly invisible when not lit
CONNECTIONS • Ethernet: 10/100 port, RJ-45 connector
• USB: (1) USB host 2.0, type A port
• Power: PoE (Power over Ethernet), 802.3af, class 0
ENVIRONMENTAL • Temperature (Operating): 32° F to 104° F (0° C to 40° C)
• Temperature (Storage): 4° F to 140° F (-20° C to 60° C)
• Humidity (Operating): 20% to 85% RH
• Humidity (Storage): 5% to 85% RH
• Power ("Heat") Dissipation:
On: 22.2 BTU/hr
Standby: 14.3 BTU/hr
INCLUDED ACCESSORIES • Installation Template 7" S Series (68-2265-02)
OPTIONAL ACCESSORIES • MXA-MP, Modero X/S Series Multi Preview (FG5968-20)
• MXA-MPL, Modero X/S Series Multi Preview Live (FG5968-10)
• PS-POE-AF-TC, PoE Injector, 802.3AF Compliant (FG423-83)
• NXA-ENET8-2POE, Gigabit PoE Ethernet Switch (FG2178-63)
• MXA-BT, Bluetooth USB Adapter for Modero X/S Series Touch Panels (FG5968-19)
• MXA-HST, Bluetooth Handset for Modero X/S Series Touch Panels (FG5968-17)
• CB-MXSA-07, Rough-In Box and Cover Plate for Modero X/S Series Touch Panel, 7"
(FG2265-09)
• MSA-MMK-07, Multi Mount Kit for 7" Modero S Series Wall Mount Touch Panel
(FG2265-12)
• MSA-RMK-07, Rack Mount Kit for Modero S Series Touch Panel, 7" (FG2265-15)
• MSA-AMK-07, Any Mount Kit for 7" Modero S Series Wall Mount Touch Panel
(FG2265-25)
• MXA-CLK, Modero X/S Series Screen Cleaning Kit (FG5968-16)
• MXA-USB-C, USB Port Covers for the Modero X/S Series Touch Panels (FG5968-18)
