4.5.1.2. Strip options
There are three possible options to be set: units, pad sensitivity and pad sequence on
printout.
4.5.1.2.1. Measurement units
Results can be displayed in different units. Use the control keys in MENU/SETUP/
STRIP/UNIT submenu to select the desired unit. The CombiScan
®
500 supports the fol-
lowing measuring units:
Conventional
SI
Arbitrary
Conventional + Arbitrary
SI + Arbitrary
4.5.1.2.2. Sensitivity adjustment
The CombiScan
®
500 provides semiquantitative results. In special cases, it may be nec-
essary to adjust the sensitivity of single parameters to special requirements of the user,
although it is not recommended by ANALYTICON. To adjust the sensitivity, enter MENU/
SETUP/STRIP/SENS submenu.
Pad measurement sensitivity can be set in two levels in both directions (+/-). The set val-
ues on the display are as follows:
– – 0 – 0 0 0 + 0 + +
2004/08/09 19:19:26
MENU/SETUP/STRIP
UNIT SENS. PADSEQ.
PAD SENSITIVITY
DEFAULT/USER DEFINE
DEFAULT SET QUIT
PAD SENSITIVITY
PAD NAME: BIL
SENSITIVITY: 0
NEXT
When SET option is selected the first PAD name with the actual setting is displayed. After
selecting the SET option the proper sensitivity of each test pad can be selected, using the
control keys. To enter the selected sensitivity of a parameter and to jump to the next
parameter, press the NEXT key. After having set the sensitivity, the program will automati-
cally return to the previous function menu. It is not possible to escape until all pad sensi-
tivities are set. To skip a pad without any modifications just select NEXT.
To get back to MAIN MENU without changing the actual settings, just press the QUIT
function key.
To reset the settings adjusted by the manufacturer for all pads select the DEFAULT option.
Going back to MAIN MENU without changing the actual settings, just press QUIT.
