IMPORTANT! The adjustment of the pad sensitivity effects the results of the
measurement! When the reader is adjusted different from manufacturer setting
it will be indicated by asterisks in the footer of the printout!
4.5.1.2.3. Pad sequence in printout
By default, the reader prints out the result in the sequence of the pads physical position
but it is also possible to customize the layout.
2004/08/09 19:19:26
MENU/SETUP/STRIP
UNIT SENS. PADSEQ.
PAD PRINTING SEQUENCE
DEFAULT/USER DEFINE
DEFAULT SET QUIT
PAD PRINTING SEQUENCE
REPORT LINE: 01
PAD NAME: BIL
NEXT
This setup option effects only the printout and data transfer!
If the PADSEQ option is selected, you can restore either the default sequence or set up
your own sequence by selecting the SET option. Selecting SET you can choose pads in
a desired sequence of the printout lines. In the second row the line number is displayed
and the third line indicates the actual parameter name. Using the control keys you can
perform changes. Pressing the NEXT option will display the next printout line. If you select
“End rep.” only the previously selected parameters will be printed out. When the last line
is reached, the program returns to PADSEQ submenu.
NOTE: You can not define empty printout lines or the same parameter twice or
more times.
4.5.1.3. Clock and date settings
The built-in digital clock enables to store the date and time of the measurement. It is
working even if the reader is turned off or the power supply is not connected. The reader
supports different date and time formats.
2004/08/09 19:19:26
MENU/SETUP
OUTPUT STRIP CLOCK
2004/08/09 19:19:26
MENU/SETUP/CLOCK
SET 12/24 SEQUENCE
2004/08/09 19:19:26
ENTER NEW DATE & TIME
>>>
