9
Operation
4. Operation
4.1. Switching on/off
Connect the CombiScan
®
500 with the power adapter to a power socket. Press the EN-
TER button if the instrument is in standby mode. The name and software version of the
instrument is displayed on the LCD for a short time. Now, one of the following alternative
options will be executed depending on the stored “working history“ of the reader.
The strip counter is not equal to zero.
This means that measurements were done since the last waste bin emptying. If you empty
it now, press the „YES“ control key and the strip counter will be set to zero. If you do not
clear the waste bin from used strips now, select „Cancel“. In this case the strip counter
will not be reset.
If there are measurement results stored in the memory at the day’s first power-on, the
programm will offer an option of deleting the memory content.
CAUTION! If you select „OK“ all data stored in memory will be erased! Chose
this option only if data have been archived, printed out or you are sure you don‘t
need them any longer!
If the memory is free and the used strip counter is set to zero at the day’s first power on,
the MAIN MENU appears on LCD.
2004/08/09 19:19:26
>>004 Combi Scan 500
<<005 V.4.01.05
WORKLIST START MENU
If you want to switch off the reader, just press the QUIT button. Answer YES when the
reader asks for confirmation. Now the CombiScan
®
500 is in standby mode.
4.2. Overview of the Menu system
The equipment is controlled by a multilevel menu system. The bottom line of the four-row
LCD indicates the actual selectable menu items – max. 3 at the same time. These menu
points can be selected by pressing the control key right below. Without any selection you
will get back to the main menu by pressing the QUIT button.
2004/08/09 19:19:26
004 Combi Scan 500
005 V.4.01.05
WORKLIST START MENU
MANUAL CombiScan500
001
000
SKIP STOP
2004/08/09 19:19:26
MENU
SETUP SERVICE MEMORY
2004/08/09 19:19:26
MENU/WORKLIST
ITEM Nr: 0
EDIT/ADD CLEAR PRINT
