Analytik Jena SPECORD 200 User Manual

Peltier temperature-controlled cell holders/cell changers
Peltier temperature-controlled cell holder, air-cooled
13.1.2 Technical data of Peltier temperature-controlled cell holder, air-cooled
Principle Thermoelectric heating and cooling
Cooling at rear panel of TEC Air-cooled
Guaranteed regulated temperature range at 25 °C
ambient temperature
+10...+60 °C on models with Type A
heat transfer
-5...+105 °C on models with Type B
heat transfer
Block temperature adjusting range -20 - +105 °C
Setting accuracy 0.1 degree
Reading accuracy 0.1 degree
Regulating accuracy +/- 0.1 degree
Overview 13-1 Technical data of Peltier temperature-controlled cell holder
Technical data of control unit
Weight of control unit 2.5 kg
Dimensions (W x H x D) 225 x 130 x 200 mm
3
Line voltage 100 - 240 V
Frequency 50 ... 60 Hz
Power consumption 75 VA
Line fuses 2 x T 2.5 A/H 250V, Type 19181
(Wickmann)
EMC (jamming and noise immunity) acc. to DIN
EN 61326 and 61326/A1
The device may be installed and
operated in all areas.
Fire resistance of the control unit case acc. to
UL94
HB / 1,6
Enclosure Protection IP 20
Data interface RS232 port
Working temperature range +15°C...+35°C
Transport and storage temperature range -40°C...+60°C
Relative humidity up to 90% (at +30°C)
Overview 13-2 Other technical data of Peltier temperature-controlled cell holder
56 User’s Manual SPECORD 200/205/210/250 – Accessories 07/2005
Analytik Jena AG
